INVT Goodrive350-19 Series Operation Manual page 481

Goodrive350-19 Series VFD for Crane
Outline dimensions
VFD model
90–110kW
H1
Figure C-9 Wall-mounting diagram for 380V 132–200kW VFD models
Outline dimensions
VFD model
132–200kW
W1
W2
H1 H2
Figure C-8 Wall mounting for 380V 90–110kW VFD models
(mm)
W1 H1 D1
338 554 330
W1
(mm)
W1 H1 D1
500 872 360
Hole distance
(mm)
diameter
(mm)
W2 H2
200 535
D1
6- ø11.0
Hole distance
(mm)
diameter
(mm)
W2 H2
180 850
-469-
Dimension drawings
D1
Hole Net
Screw weight
(kg)
ø 10 M8
W2
H2
Hole
Screw weight
(kg)
ø 11 M10
Gross
weight
(kg)
41 52
W2
Net Gross
weight
(kg)
85 110
