Goodrive350-19 Series VFD for Crane
Function
Name
code
AO3 output
P26.44 corresponding to
lower limit
AO3 output upper
P26.45
limit
AO3 output
P26.46 corresponding to
upper limit
P26.47 AO3 output filter
time
Group P27––Programmable expansion card functions
Function
Name
code
Enabling
P27.00 programmable card
functions
P27.01 C_WrP1
P27.02 C_WrP2
P27.03 C_WrP3
P27.04 C_WrP4
P27.05 C_WrP5
P27.06 C_WrP6
Description
10V (20mA)
AO
0.0%
Setting range of P26.38: -300.0%–P26.40
Setting range of P26.39: 0.00V–10.00V
P26.40 setting range: P26.38–300.0%
Setting range of P26.41: 0.00V–10.00V
Setting range of P26.42: 0.000s–10.000s
Setting range of P26.43: -300.0%–P26.45
Setting range of P26.44: 0.00V–10.00V
P26.45 setting range: P26.43–300.0%
Setting range of P26.46: 0.00V–10.00V
Setting range of P26.47: 0.000s–10.000s
Description
0: Disable
1: Enable
0–65535
Note: Used to write a value to WrP1 of the
programmable card.
0–65535
Note: Used to write a value to WrP2 of the
programmable card.
0–65535
Note: Used to write a value to WrP3 of the
programmable card.
0–65535
Note: Used to write a value to WrP4 of the
programmable card.
0–65535
Note: Used to write a value to WrP5 of the
programmable card.
0–65535
-286-
Function parameters
Default Modify
0.00V
100.0%
100.0%
10.00V
0.000s
Default Modify
0
0
0
0
0
0
0
○
○
○
○
◎
○
○
○
○
○
◎
