Goodrive350-19 Series VFD for Crane
The following table lists expansion cards that the VFD supports. The expansion cards are optional
and need to be purchased separately.
Name
I/O
expansion EC-IO501-00
card 1
I/O
expansion EC-IO502-00
card 2
WIFI
EC-TX502-1/
communicati
EC-TX502-2
on card
PROFIBUS-
DP
EC-TX503D
communicati
on card
Ethernet
communicati EC-TX504
on card
CANopen/
CAN
EC-TX505D
master/slave
communicati
Model
● 4 digital inputs
● 1 digital output
● 1 analog input
● 1 analog output
● 2 relay outputs: 1 double-contact output,
and 1 single-contact output
● 4 digital inputs
● One PT100
● One PT1000
● 2 relay outputs: single-contact NO
Note: The card is standard configuration
only for 7.5kW and higher models.
● Meeting requirements of IEEE802.11b/g/n
● With INVT's mobile phone APP, you can
monitor the VFD locally or remotely through
WIFI
● The maximum communication distance in
open environments is 30m
● EC-TX502-1 with a built-in antenna,
applicable to molded case machines
● EC-TX502-2 with an external sucker
antenna, applicable to sheet metal
machines
● Supporting the PROFIBUS-DP protocol
● Supporting Ethernet communication with
INVT's internal protocol
● Can be used in combination with INVT's
host controller monitoring software INVT
Workshop
● Based on the CAN2.0A physical layer
● Supporting the CANopen protocol
● Adopting INVT's master-slave control
proprietary protocol
Specifications
-414-
Expansion card
Order No.
11023–00083
11023–00119
11023-00101/
11023–00102
11023–00080
11023–00081
11023–00164
