Function
Name
code
Estimated motor
P17.10
frequency
P17.11 DC bus voltage
Digital input
P17.12
terminal state
Digital output
P17.13
terminal state
Digital adjustment
P17.14
value
Torque reference
P17.15
value
P17.16 Linear speed
P17.17 Reserved
P17.18 Count value
P17.19 AI1 input voltage
P17.20 AI2 input voltage
HDIA input
P17.21
frequency
HDIB input
P17.22
frequency
PID reference
P17.23
value
Description
Displays the estimated motor rotor frequency
under the open-loop vector condition.
Range: 0.00–P00.03
Displays the present DC bus voltage of the
VFD.
Range: 0.0–2000.0 V
Displays the present digital input terminal state
of the VFD.
Range: 0x00–0x3F
Corresponds to HDIB, HDIA, S4, S3, S2 and S1
respectively.
Displays the present digital output terminal
state of the VFD.
Range: 0x0–0xF
The bits correspond to RO2, RO1, HDO, and
Y1 respectively.
Displays the adjustment on the VFD made
through the UP/DOWN terminal.
Range: 0.00Hz–P00.03
Relative to the percentage of the rated torque of
the present motor, displaying the torque
reference.
Range: -300.0%–300.0% (of the motor rated
current)
0–65535
0–65535
0–65535
Displays the AI1 input signal.
Range: 0.00–10.00V
Displays the AI2 input signal.
Range: -10.00V–10.00V
Displays HDIA input frequency.
Range: 0.000–50.000kHz
Displays HDIB input frequency.
Range: 0.000–50.000kHz
Displays the PID reference value.
Range: -100.0–100.0%
-251-
Function parameters
Default Modify
●
0.00Hz
●
0V
●
0x00
●
0
●
0.00Hz
●
0.0%
●
0
●
0
●
0
●
0.00V
●
0.00V
●
0.000kHz
●
0.000kHz
●
0.0%
