Goodrive350-19 Series VFD for Crane
Function description
Output frequency
Control mode
Motor type
Speed ratio
Speed control
accuracy
Technical
control
Speed fluctuation
performance
Torque response
Torque control
accuracy
Starting torque
Overload capacity 150% for 1 minute, 180% for 10 seconds, and 200% for 1 second
Braking capability 100% for long time, 120% for 1 minute, and 160% for 10 seconds
Frequency setting
Running
control
Automatic voltage
performance
regulation
Fault protection
Braking protection
Specialized
functions
Brake control
(kW)
0–150Hz
(Hz)
Space voltage vector control mode
Sensorless vector control (SVC) mode
Feedback vector control (FVC) mode
Asynchronous motor (AM) and permanent magnetic
synchronous motor (SM)
1: 200 (SVC)
1: 1000 (FVC)
± 0.2% (SVC)
± 0.02% (FVC)
± 0.3% (SVC)
± 0.02% (FVC)
< 20ms (SVC)
< 10ms (FVC)
10% (SVC)
5% (FVC)
For AMs: 0.25Hz/150% (SVC)
For AMs: 2.5Hz/150% (SVC); 0Hz/200% (FVC)
Settings can be implemented through digital, analog, pulse
frequency, multi-step speed running, simple PLC, PID, Modbus
communication, PROFIBUS-DP communication and so on.
method
Settings can be combined and the setting channels can be
switched.
The output voltage can be kept constant although the grid
voltage changes.
More than 30 protection functions, such as protection against
overcurrent, overvoltage, undervoltage, overtemperature, phase
loss, and overload.
The 30–110 kW VFD models provide the function of protecting
against braking resistor short connection, braking unit short
connection, and PB-PE short connection.
Embedded with hoisting-oriented brake logic, and integrated with
the torque verifying, brake feedback, zero position detection,
restart after braking functions, which meet the industrial
standards on the VFDs for cranes.
Specifications
