INVT Goodrive350-19 Series Operation Manual page 250

Goodrive350-19 Series VFD for Crane Function parameters
Function
Name Description Default Modify
code
12: AI1 (×100, V)
13: AI2 (×100, V)
14: AI3 input (x100, V)
15: HDIA frequency value (×100, kHz)
16: Terminal input status
17: Terminal output status
18: PID reference (×100, %)
19: PID feedback (×100, %)
20: Motor rated torque
21: High bit of position reference (signed)
22: Low bit of position reference (unsigned)
23: High bit of position feedback (signed)
24: Low bit of position feedback (unsigned)
25: Status word 2
26: HDIB frequency value (×100, kHz)
27: PG card pulse feedback count high bit
28: PG card pulse feedback count low bit
29: Brake status
30: Non-standard status
31: Reserved
32: Encoder feedback frequency
(-Fmax–Fmax, unit: 0.01Hz)
33–51: Reserved
52: Module temperature
53: U-phase current transient value
54: V-phase current transient value
55: W-phase current transient value
56–57: Reserved
58: Load weight
59: Current peak value
60: Filter torque setting (filter after running)
61: MWh electromotive status (high bit)
62: kWh status (low bit) (×10, kWh)
63: MWh electricity generation status (high bit)
64: kWh electricity generation status (low bit)
(×10, kWh)
65: PG card pulse reference count high bit
66: PG card pulse reference count low bit
67: Function parameter mapping
-238-
