Goodrive350-19 Series VFD for Crane
terminal function description:
Signal
PE
PWR
Encoder power
PGND
A1+
A1-
B1+
B1-
Z1+
Z1-
A.6.6 24V simplified incremental PG card (EC-PG507-24)
The terminals are arranged as follows:
PE
PGND
Indicator definition:
Indicator Definition
LED1 Status indicator
Disconnection
LED2
LED3 Power indicator
Port
Grounding Connected to the ground to enhance the anti-interference
terminal performance
Voltage: 5V/12V ± 5%
Max. output: 150 mA
Select the voltage class through SW1 based on the voltage class
of the used encoder. (PGND is the isolation power ground.)
1. Applicable to 5V/12V push-pull encoders
2. Applicable to 5V/12V OC encoders
Encoder
3. Applicable to 5V differential encoders
interface
4. Response frequency: 400kHz
5. Supporting the encoder cable length of up to 50m
A1+
A1-
On: The expansion card is connecting with the control board.
Blinking periodically (cycle: 1s; on: 0.5s; off: 0.5s): The expansion
card is connected with the control board.
Off: The expansion card is disconnected from the control board.
On: Encoder pulses are normal.
indicator Off: A1 or B1 of the encoder is disconnected.
This indicator is on after the control board feeds power to the
expansion card.
Description
B1+ Z1+
B1- Z1-
Function
-451-
Expansion card
PWR
PGND
