INVT Goodrive350-19 Series Operation Manual page 226

Goodrive350-19 Series VFD for Crane
Function
Name
code
Simple PLC
P10.01
memory selection
P10.02 Multi-step speed 0 Frequency setting range for steps from step 0
Running time of
P10.03
step 0
P10.04 Multi-step speed 1
Running time of
P10.05
step 1
P10.06 Multi-step speed 2
Running time of
P10.07
step 2
P10.08 Multi-step speed 3
Running time of
P10.09
step 3
P10.10 Multi-step speed 4
Running time of
P10.11
step 4
P10.12 Multi-step speed 5
Running time of
P10.13
step 5
P10.14 Multi-step speed 6
Running time of
P10.15
step 6
P10.16 Multi-step speed 7
Running time of
P10.17
step 7
P10.18 Multi-step speed 8
Running time of
P10.19
step 8
P10.20 Multi-step speed 9
Description
one cycle, and it can be started only after
receiving the running command.
1: Keep running with the final value after
running once
The VFD keeps the running frequency and
direction of the last section after a single cycle.
2: Cyclic running
The VFD enters the next cycle after completing
one cycle until receiving the stop command.
0: Do not memorize at power outage
1: Memory at power-off. The PLC memories its
running stage and running frequency before
power-off.
to step 15:
corresponds to the max. output frequency
P00.03.
Running time setting range for steps from step
0 to step 15: 0.0–6553.5s(min). The time unit is
specified by P10.37.
When simple PLC operation is selected, it is
required to set P10.02–P10.33 to determine the
running frequency and running time of each
step.
Note: The symbol of multi-step speed
determines the running direction of simple
PLC, and the negative value means reverse
running.
Deceleration time
(two sections)
P10.04
P10.02
Acceleration time
(two sections)
P10.03 P10.05 P10.07
When selecting multi-step speed running, the
multi-step speed is within the range of
-Fmax–Fmax, and it can be set continuously.
The start/stop of multi-step stop running is also
determined by P00.01.
The VFD supports the setting of 16-step speed,
which are set by combined codes of multi-step
-214-
-100.0–100.0%. 100.0%
P10.28
P10.30
P10.06
P10.31 P10.33
Function parameters
Default Modify
0
0.0%
0.0s(min)
0.0%
0.0s(min)
0.0%
0.0s(min)
0.0%
0.0s(min)
0.0%
0.0s(min)
0.0%
P10.32 0.0s(min)
0.0%
0.0s(min)
0.0%
0.0s(min)
0.0%
0.0s(min)
0.0%
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
