Goodrive350-19 Series VFD for Crane
C.5 Dimensions of AC 3PH 380V (-15%)–440V (+10%)
C.5.1 Wall mounting dimensions
W1
H1
VFD model
1.5kW–2.2kW
4kW–5.5kW
7.5kW
11kW–15kW
18.5kW–22kW
30kW–37kW
Outline dimensions
VFD model
W1
45–75kW 282
Figure C-6 Wall mounting for 380V 1.5–37kW VFD models
Outline dimensions
(mm)
W1 H1 D1
126 186 185
126 186 201
146 256 192
170 320 220
200 340.6 208
250 400 223
W1
W2
H1 H2
W3
Figure C-7 Wall mounting for 380V 45–37kW VFD models
(mm)
H1 D1
560 258
D1
Hole distance
(mm)
W2 H2
115 175
115 175
131 243.5
151 303.5
185 328.6
230 380
Hole distance (mm)
W2 W3 H2
160 226 542
-468-
Dimension drawings
H2
Hole
diameter Screw weight
(mm)
ø
5 M4
ø
5 M4
ø
6 M5
ø
6 M5
ø
6 M5
ø
6 M5
D1
Hole
diameter Screw weight
(mm)
ø 9 M8
W2
Net Gross
weight
(kg) (kg)
2 3
2.5 3.5
3 4
6 7
8.5 10.5
16 17
Net Gross
weight
(kg) (kg)
25 29
