Goodrive350-19 Series VFD for Crane
Indicator
LED4
Net port
indicator
(Link indicator)
Net port
indicator
(ACK indicator)
For details, see the Goodrive350 series VFD communication card manual.
A.5.7 CAN-NET two-in-one communication card (EC-TX511B)
The EC-TX511B communication card is user-friendly, adopting spring-loaded terminals. CN2 uses
standard RJ45 terminals.
CN3 terminal function:
3-pin
spring-loaded
terminal
1 2 3
Terminal resistor switch function description:
Terminal resistor
switch
Color
Off: No fault
Red 3.3V power indicator
On: Ethernet connection is successful.
Yellow Off: Ethernet connection is not established.
On: Data exchange is ongoing.
Green On: Data exchange is ongoing.
Pin
1
2
3
Position value
Left
Right
Function
Function
CANH CANopen bus high level signal
CANG CANopen bus shielding
CANL CANopen bus low level signal
Function
No terminal resistor is connected
OFF
between CAN_H and CAN_L.
A 120 Ω terminal resistor is connected
ON
between CAN_H and CAN_L.
-433-
Expansion card
Description
Description
