INVT Goodrive350-19 Series Operation Manual page 203

Goodrive350-19 Series VFD for Crane
Function
Name
code
time
AO1 output current
P06.23
setting
PTC resistance
P06.24
alarm threshold
PTC resistance
P06.25 alarm recovery
threshold
Actual PTC
P06.26
resistance
HDO output lower
P06.27
limit
HDO output
P06.28 corresponding to
lower limit
HDO output upper
P06.29
limit
HDO output
P06.30 corresponding to
upper limit
HDO output filter
P06.31
time
P06.33 Detection value for 0Hz–P00.03
Description
10V (20mA)
AO
0.0%
P06.17 setting range: -300.0%–P06.19
P06.18 setting range: 0.00V–10.00V
P06.19 setting range: P06.17–300.0%
P06.20 setting range: 0.00V–10.00V
P06.21 setting range: 0.000s–10.000s
Applicable to P92.22=4 (using PTC for
temperature measuring). Refer to section 5.7.3
Using PTC. Set P06.24 and P06.25 according
to the selected PTC model resistance and
temperature curve.
When P06.26 is greater than P06.24, the VFD
reports the alarm A-Aot and runs normally.
When P06.26 is less than P06.25, the alarm
A-Aot is cleared.
Setting range of P06.23: 0.00–20.000mA
Setting range of P06.24: 0–60000Ω
Setting range of P06.25: 0–60000Ω
Setting range of P06.26: 0–60000Ω
-300.0%–P06.29
0.00–50.00kHz
P06.27–300.0%
0.00–50.00kHz
0.000s–10.000s
-191-
Function parameters
Default Modify
100.0%
4.000mA
750Ω
150Ω
0Ω
0.00%
0.00kHz
100.0%
50.00kHz
0.000s
1.00Hz
○
○
○
●
○
○
○
○
○
○
