INVT Goodrive350-19 Series Operation Manual page 124

Goodrive350-19 Series VFD for Crane
Function
code
corresponding to lower
P06.19 AO1 output upper limit
P06.20 corresponding to upper
P06.21 AO1 output filter time
Slave parameters:
Function
code
P03.11 Torque setting method 2: AI1
P03.32 Enabling torque control 1: Enable
P05.24 AI1 lower limit
Corresponding setting
P05.25
of AI1 lower limit
P05.26 AI1 upper limit
Corresponding setting
P05.27
of AI1 upper limit
P05.28 AI1 input filter time
Note: When the terminal master/slave function is used, commissioning is unrelated to P28.
5.5.3 Master/slave communication
The VFDs can implement the master/slave control function by using the CAN master/slave
communication card. The wiring diagram is as follows.
Master
CAN
master/slave
communication
card
The specific CAN communication master/slave modes are: master/slave mode 0–2 are master/slave
power balance modes, master/slave mode 4 is the closed-loop speed synchronization mode, and
master/slave mode 3 is reserved. Master/slave mode 0 and master/slave mode 1 are used often.
Name
P06.19 setting range: P06.17–300.0%
limit P06.20 setting range: 0.00V–10.00V
P06.21 setting range: 0.000s–10.000s
AO1 output
limit
Name
P05.24 setting range: 0.00V–P05.26
P05.25 setting range: -300.0%–300.0%
P05.26 setting range: P05.24–10.00V
P05.27 setting range: -300.0%–300.0%
P05.28 setting range: 0.000s–10.000s
VFD
CANH
CANL
Description
Description
Slave
-112-
Commissioning guidelines
VFD
CAN
CANH
master/slave
communication
CANL
card
Setting
100.0%
10.00V
0.000s
Setting
2
1
0.00V
0.0%
10.00V
100.0%
0.030s
