Goodrive350-19 Series VFD for Crane
Name
Resolver PG
EC-PG504-00
card
Multi-functio
n
EC-PG505-12
incremental
PG card
Simplified
incremental
EC-PG507-12B
PG card
24V
simplified
EC-PG507-24
incremental
PG card
Absolute
encoder SSI
EC-PG508-05B
communicati
on PG card
4G
expansion
EC-IC502-2
card
24V power
supply
EC-PS501-24
expansion
card
Model
of A, B, and Z
● Supporting pulse train reference input
● Applicable to resolver encoders
● Supporting frequency-divided output of
resolver-simulated A, B, and Z
● Supporting pulse train reference input
● Applicable to OC encoders of 5V or 12V
● Applicable to push-pull encoders of 5V or
12V
● Applicable to differential encoders of 5V
● Supporting A, B, and Z orthogonal input
● Supporting the frequency-divided output
of A, B, and Z
● Supporting pulse train reference input
● Applicable to OC encoders of 5V or 12V
● Applicable to push-pull encoders of 5V or
12V
● Applicable to differential encoders of 5V
● Applicable to OC encoders of 24V
● Applicable to push-pull encoders of 24V
● Applicable to differential encoders of 24V
● SSI signal, differential input of 5V
● Applicable to encoders of 24V or 5V
● Pulse reference supporting 5V differential,
24V push-pull, and OC encoders
● Supporting standard RS485 interfaces
● Supporting 4G communication
● Input voltage range: DC18–30V(Rated
24VDC)/2A
● Three channels of output voltage: +5V/1A
(±5%), +15V/0.2A (±10%), -15V/0.2A
(±10%)
Specifications
-416-
Expansion card
Order No.
11023–00086
11023–00087
17001–05975
11023–00121
11023–00177
11095–00009
11023–00135
