INVT Goodrive350-19 Series Operation Manual page 243

Goodrive350-19 Series VFD for Crane
Function
Name
code
Initial
P13.10 compensation
angle of SM
Mal-adjustment
P13.11
detection time
SM high-frequency
P13.12 compensation
coefficient
High-frequency
P13.13
pull-in current
Identifying initial
pole angle after SM
P13.14
dual PG card
switchover
Group P14—Serial communication
Function
Name
code
Local
P14.00 communication
address
Communication
P14.01
baud rate setting
Description
the phase-locked loop is enabled.
Setting range: 0–655.35
0.0–359.9
Used to adjust the responsiveness of
anti-maladjustment function. If the load inertia is
large, increase the value of this parameter
properly, however, the responsiveness may
slow down accordingly.
Setting range: 0.0–10.0s
Valid when the motor speed exceeds the rated
speed. If oscillation occurred to the motor,
adjust this parameter properly.
Setting range: 0.0–100.0%
0–300.0% (of the rated VFD output current)
0: Identify again after switchover
1: Do not identify after switchover
Description
Setting range: 1–247
When the master
communication address to 0 indicating a
broadcast address in a frame, all the salves on
the Modbus bus receive the frame but do not
respond to it. The communication addresses on
the communication network are unique, which
is the basis of the point-to-point communication.
Note: The communication address of a
slave cannot be set to 0.
The function code is used to set the rate of data
transmission between the upper computer and
the VFD.
0: 1200 bps
-231-
writes the slave
Function parameters
Default Modify
○
0.0
○
0.5s
○
0.0%
◎
20.0%
◎
0
Default Modify
○
1
○
4
