Goodrive350-19 Series VFD for Crane
Function
Name
code
coefficient 4 of iron
core of AM 3
Rated power of SM
P89.15
Rated frequency of
P89.16
SM 3
Number of pole
P89.17
pairs of SM 3
Rated voltage of
P89.18
SM 3
Rated current of
P89.19
SM 3
Stator resistance of
P89.20
SM 3
Direct-axis
P89.21
inductance of SM 3
Quadrature-axis
P89.22
inductance of SM 3
Counter-emf
P89.23
constant of SM 3
Initial pole position
P89.24
of SM 3 (reserved)
Identification
P89.25
current of SM 2
(reserved)
Overload protection
P89.26
selection of motor 3
Overload protection
P89.27
coefficient of motor
Power display
calibration
P89.28
coefficient of motor
0.1–3000.0kW
3
0.01Hz–P00.03 (Max. output frequency)
1–128
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.01–655.35mH
0.01–655.35mH
0–10000V
0x0000–0xFFFF
0%–50% (of the motor rated current)
0: No protection
1: Common motor (with low-speed
compensation)
2: Frequency-variable motor (without low-speed
compensation)
20.0%–150.0%
3
0.00–3.00
3
Description
-298-
Function parameters
Default Modify
Model
depended
50.00Hz
2
Model
depended
Model
depended
Model
depended
Model
depended
Model
depended
300V
0x0000
10%
2
100.0%
1.00
