Goodrive350-19 Series VFD for Crane
Function
Name
code
Output terminal
P06.05
polarity selection
P06.06 Y1 switch-on delay
P06.07 Y1 switch-off delay
HDO switch-on
P06.08
delay
HDO switch-off
P06.09
delay
RO1 switch-on
P06.10
delay
RO1 switch-off
P06.11
delay
RO2 switch-on
P06.12
delay
RO2 switch-off
P06.13
delay
Description
55: Overload protection
56: Brake detection reminding
57: Brake failure alarm
58: Input phase loss alarm
59: Loose rope status (Loose rope fault in REV
lowering)
60: In motor 1 state
61: In motor 2 state
62: In motor 3 state
63: PT100 temperature alarm
64: PT1000 temperature alarm
65: Boosting the speed with light load
66: Frequency decrease with voltage
67: Weighing alarm
68: AI detected temperature alarm
69: Reserved
70: Stopped or running in zero speed
71: Input power failure
The function code is used to set the polarity of
output terminals.
When a bit is 0, the output terminal is positive.
When a bit is 1, the output terminal is negative.
BIT3 BIT2
RO2 RO1
Setting range: 0x0–0xF
The function codes specify the delay time
corresponding to the electrical level changes
when the programmable output terminals
switch on or switch off.
Y electric level
Invalid
Y valid
Switch on
delay
Setting range: 0.000–50.000s
Note: P06.08 and P06.09 are valid only when
P06.00=1.
-188-
BIT1 BIT0
HDO Y1
invalid
Valid
Switch off
delay
Function parameters
Default Modify
○
0x0
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
