INVT Goodrive350-19 Series Operation Manual page 35

Vfd for crane
Hide thumbs Also See for Goodrive350-19 Series:

Advertisement

Goodrive350-19 Series VFD for Crane
Environment
humidity (RH)  Condensation is not allowed.
 The max. RH cannot exceed 60% in the environment where there are
Storage
-30–+60.0° C
temperature
Install the VFD in a place:
 Away from electromagnetic radiation sources
 Away from oil mist, corrosive gases, and combustible gases
 Without the chance for foreign objects such as metal powder, dust, oil and
Running
environment
 Without radioactive substances and combustible objects
 Without hazard gases and liquids
 With low salt content
 Without direct sunlight
 Lower than 1000 meters
 When the altitude exceeds 1000m, derate by 1% for every increase of 100m.
Altitude
 When the installation site altitude exceeds 3000m, consult the local INVT
Vibration
The max. amplitude of vibration cannot exceed 5.8m/s
Installation
Install the VFD vertically to ensure good heat dissipation performance.
direction
Note:
The VFD must be installed in a clean and well-ventilated environment based on the housing IP
rating.
The cooling air must be clean enough and free from corrosive gases and conductive dust.
4.2.2 Installation direction
The VFD can be installed on the wall or in a cabinet.
The VFD must be installed vertically. Check the installation position according to following
requirements. For details about the outline dimensions, see Appendix C Dimension drawings.
corrosive gases.
water to fall into the VFD (do not install the VFD onto combustible objects such
as wood)
dealer or office.
Condition
-23-
Installation guidelines
2
(0.6g).
