INVT Goodrive350-19 Series Operation Manual page 323

Goodrive350-19 Series VFD for Crane
Function
Name
code
Contactor control
P91.04
selection
Contactor feedback
P91.05
detection time
Enabling operating
lever zero point
P91.06
position detection
Operating lever
P91.07 zero point position
delay
Description
Output
frequency
Rated
frequency
P04.07
P04.05
P04.03
Output
voltage V
(%)
P91.01
P91.01*P04.08
P91.01*P04.06
P91.01*P04.04
Torque boost
voltage (%)
Start
command
Brake
action
The conical motor
simultaneously with the multi-dot V/F function.
Note:

The torque boost voltage is related to
P04.01.

The I/F mode is not applicable to conical
motors.
0–1
0: Controlled by an external controller
1: Controlled by the VFD
0.00–20.000s
0x00–0x11
Ones place:
0: Disable zero point position detection
1: Enable zero point position detection
Tens place:
0: Do not detect AI2 after zero position
detection
1: Detect AI2 after zero position detection
After the zero position detection signal is
enabled, the terminal zero position signal is
given in stop state, the zero position detection
is completed (valid) with a delay specified by
P91.07, the zero position signal is released,
and the VFD runs only after being given with
the running command. After the zero position
-311-
Time t
Output
voltage V
(%)
P91.02
P91.03
P91.03*P04.08
P91.03*P04.06
P91.03*P04.04
Time t
function is used
Function parameters
Default Modify
◎
0
◎
1.000s
◎
0x00
○
0.300s
