Goodrive350-19 Series VFD for Crane
cable length.
Non-shielded
cable length
Shielded cable
length
Output reactor
category
D.7.1 AC 3PH 380V(-15%)–440V(+10%)
VFD power
1.5kW
2.2kW
4kW
5.5kW
7.5kW
11kW
15kW
18.5kW
22kW
30kW
37kW
45kW
55kW
75kW
90kW
110kW
132kW
160kW
185kW
200kW
220kW
250kW
280kW
Table D-5 Reactors for AC 3 PH 380V (-15%)–440V (+10%)
50m–150m
30m–100m
Output reactor (1%)
/
/
Table D-6 Reactors for 380V
Input reactor
GDL-ACL0005-4CU
GDL-ACL0006-4CU
GDL-ACL0014-4CU
GDL-ACL0020-4CU
GDL-ACL0025-4CU
GDL-ACL0035-4AL
GDL-ACL0040-4AL
GDL-ACL0051-4AL
GDL-ACL0051-4AL
GDL-ACL0070-4AL
GDL-ACL0090-4AL
GDL-ACL0110-4AL
GDL-ACL0150-4AL
GDL-ACL0150-4AL
GDL-ACL0220-4AL
GDL-ACL0220-4AL
GDL-ACL0265-4AL
GDL-ACL0330-4AL
GDL-ACL0390-4AL
GDL-ACL0390-4AL
GDL-ACL0450-4AL
GDL-ACL0500-4AL
GDL-ACL0500-4AL
150m–450m
100m–230m
/
dv/dt filter
/
DC reactor
-
-
-
-
-
-
-
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
GDL-DCL0300-4AL
GDL-DCL0365-4AL
GDL-DCL0455-4AL
GDL-DCL0455-4AL
GDL-DCL0505-4AL
GDL-DCL0550-4AL
GDL-DCL0675-4AL
-504-
Optional peripheral accessories
450m–1000m
230m–500m
/
/
Sine-wave filter
Output reactor
GDL-OCL0005-4CU
GDL-OCL0006-4CU
GDL-OCL0010-4CU
GDL-OCL0014-4CU
GDL-OCL0020-4CU
GDL-OCL0025-4CU
GDL-OCL0035-4AL
GDL-OCL0040-4AL
GDL-OCL0050-4AL
GDL-OCL0060-4AL
GDL-OCL0075-4AL
GDL-OCL0092-4AL
GDL-OCL0115-4AL
GDL-OCL0150-4AL
GDL-OCL0220-4AL
GDL-OCL0220-4AL
GDL-OCL0265-4AL
GDL-OCL0330-4AL
GDL-OCL0400-4AL
GDL-OCL0400-4AL
GDL-OCL0450-4AL
GDL-OCL0500-4AL
GDL-OCL0560-4AL
