Goodrive350-19 Series VFD for Crane
Function
Name
code
P25.09 Function of HDI3
Expansion card
P25.10 input terminal
polarity
Expansion card
virtual terminal
P25.11
setting
HDI3 switch-on
P25.12
delay
HDI3 switch-off
P25.13
delay
P25.14 S5 switch-on delay
P25.15 S5 switch-off delay
P25.16 S6 switch-on delay
P25.17 S6 switch-off delay
P25.18 S7 switch-on delay
P25.19 S7 switch-off delay
P25.20 S8 switch-on delay
P25.21 S8 switch-off delay
P25.22 S9 switch-on delay
P25.23 S9 switch-off delay
S10 switch-on
P25.24
delay
S10 switch-off
P25.25
delay
S11 switch-on
P25.26
Description
0x000–0x1FF
BIT7 BIT6
S12 S11
BIT3 BIT2
S8 S7
0x000–0x1FF (0: Disable. 1: Enable)
Bit0: S5 virtual terminal
Bit1: S6 virtual terminal
Bit2: S7 virtual terminal
Bit3: S8 virtual terminal
Bit4: S9 virtual terminal
Bit5: S10 virtual terminal
Bit6: S11 virtual terminal
Bit7: S12 virtual terminal
Bit8: HDI3 virtual terminal
The function codes specify the delay time
corresponding to the electrical level changes
when the programmable input terminals switch
on or switch off.
Si electrical level
invalid
Si valid
Switch-on
delay
Setting range: 0.000–50.000s
-281-
BIT8
HDI3
BIT5 BIT4
S10 S9
BIT1 BIT0
S6 S5
invalid
valid
Switch-off
delay
Function parameters
Default Modify
◎
0
○
0x000
◎
0x000
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
