Goodrive350-19 Series VFD for Crane
Grounding position of
the shielded cable
A.4 IO card (EC-IO501-00)
The terminals are arranged as follows:
CME and COM are shorted through J3 before delivery, and J5 is the jumper for selecting the output
type (voltage or current) of AO2.
AI3
COM CME
PW +24V
Indicator definition:
Indicator
LED1
LED4
Figure A-4 Expansion card grounding
Y2 S5
S6 S7
Definition
On: The expansion card is connecting with the control
board.
Blinks periodically (cycle: 1s; on: 0.5s; off: 0.5s): The
Status indicator
expansion card is connected with the control board.
Off: The expansion card is disconnected from the
control board.
Power indicator On: The I/O expansion card is powered on by the
Grounding position of the
shielded cable
AO2
RO3A
S8
Function
-422-
Expansion card
GND
RO3B RO3C
RO4A RO4C
