INVT Goodrive350-19 Series Operation Manual page 371

Goodrive350-19 Series VFD for Crane
Fault
Fault type
code
[100]
E-Pdn
backward limit position
[101] Fault of instant
E-CL
stop at load change
8.5.2 Alarms and solutions
Note: The numbers enclosed in square brackets such as [1], [2] and [3] in the Alarm code
column in the following table indicate the VFD alarm type codes read through communication.
Alarm
Alarm type
code
[1] Input phase loss
A-SPI
[2] Upward limit
A-LU
position alarm
[3] Downward
A-Ld
position limit alarm
[4] Low voltage
A-LvP
[5] Overload
A-OL
protection alarm
The position feedback from
SSI position the position sensor has
exceeded the maximum
software limit position.
When P93.20 hundreds
place=1, the lifting
mechanism detects a
sudden load change after the
load is lifted off the ground.
During stop, a loss of either
input phase R, S, or T occurs
alarm
or fluctuation is great.
The input terminal has set the
upward
reaching function, and there is
a signal reference to the
terminal.
The input terminal has set the
downward
reaching function, and there is
a signal reference to the
terminal.
The bus voltage is too low.
alarm
Load is too large.
Overload
Possible cause
Possible cause
limited position
limited position
protection
-359-
Troubleshooting
Solution
software limit position settings
P11.63 and P11.64 are proper.
Check whether the feedback
from the position sensor is
proper.
Check whether the maximum
software limit position settings
P11.61 and P11.62 are proper.
Check whether there are any
exceptions in the
operation of the
mechanism.
Solution
Check the input power and
wiring.
Check whether the
highest position point has been
reached.
Check the input terminal signal.
Check whether the
lowest position point has been
reached.
Check the input terminal signal.
Check whether the
protection point is too high.
Check whether the grid voltage
or rectifier module is abnormal.
Check whether the load is too
large.
upward
lifting
allowed
allowed
voltage
