Goodrive350-19 Series VFD for Crane
Name
on card
EtherCAT
communicati EC-TX508
on card
PROFINET
communicati EC-TX509C
on card
EtherNet IP
communicati EC-TX510
on card
CAN-NET
two-in-one
EC-TX511B
communicati
on card
Modbus
TCP
EC-TX515
communicati
on card
Sin/Cos PG
EC-PG502
card
Incremental
PG card with EC-PG503-05
UVW
Model
● Supporting the EtherCAT COE 402
protocol and automatic network address
configuration
● Supporting the PDO and SDO service and
supporting the use of SDO to read VFD
function codes
● Not supporting EtherCAT synchronization
cycle
● Supporting the PROFINET protocol
● Supporting the EtherNet IP protocol
● Equipped with two EtherNet IP ports,
supporting 10/100M half/full duplex
operating
● Supporting Ethernet communication with
INVT's internal protocol
● Can be used in combination with INVT's
host controller monitoring software INVT
Workshop
● Based on the CAN2.0A physical layer;
supporting the CANopen protocol
● Supporting the Modbus TCP protocol and
Modbus TCP slave nodes
● Equipped with two Modbus TCP ports,
supporting 10/100M half/full duplex
operating
● Applicable to Sin/Cos encoders with or
without CD signals
● Supporting A, B, Z frequency-divided
output
● Supporting pulse train reference input
● Applicable to differential encoders of 5V
● Supporting A, B, and Z orthogonal input
● Supporting pulse input of phase U, V, and
W
● Supporting the frequency-divided output
Specifications
-415-
Expansion card
Order No.
11023–00120
11023–00149
11023–00107
11023–00124
11023–00125
11023–00109
11023–00085
