Goodrive350-19 Series VFD for Crane
4.3 Standard wiring of the main circuit
4.3.1 Main circuit wiring diagram
3PH power
380V± 15%
50/60Hz
3PH power
380V±15%
50/60Hz
Figure 4-7 Main circuit wiring diagram for AC 3PH 380V(-15%) – 440V(+10%)
Note:
The fuse, DC reactor, braking unit, braking resistor, input reactor, input filter, output reactor and
output filter are optional parts. For details, see Appendix D Optional peripheral accessories.
P1 and (+) have been short connected by default for the 380V 132kW and higher VFD models. If
you need to connect an external DC reactor, take off the jumper between P1 and (+).
Before connecting the braking resistor, remove the yellow warning label with PB, (+) and (-) from
the terminal block; otherwise, poor contact may occur.
3PH power
660V± 15%
50/60Hz
Fuse
Figure 4-8 Main circuit wiring diagram for AC 3PH 520V(-15%) – 690V(+10%)
R
Input
VFD models of 110kW and
reactor
S
Input
filter
T
Fuse
DC reactor
P1
Input
R
VFD models of 132kW and
reactor
S
Input
filter
T
Fuse
DC reactor
(+)
P1
R
Input
reactor
VFDs of 22kW and higher
S
Input filter
T
Braking resistor
(+)
(-)
PB
lower
Braking unit
DC+
DC-
(+)
(-)
higher
Braking unit
DC+
DC-
(-)
-28-
Installation guidelines
U
Output
reactor
V
Output
W
filter
PE
Braking resistor
U
Output
reactor
V
Output
W
filter
PE
Braking
resistor
Output
U
reactor
V
Output
filter
W
PE
M
M
M
