Goodrive350-19 Series VFD for Crane
Symbol
CAN negative
CANL
RS485 terminal
485
resistor switch
CAN terminal
CAN
resistor switch
Note: For this card, before power-on, set the SW2 switch according to the mapping between
protocols and positions.
1
OFF
ON
Indicator definition:
Indicator Definition
Status
LED1
indicator
Run
LED2
indicator
Fault
LED3
indicator
Power
LED4
indicator
For details, see the Goodrive350 series VFD communication card manual.
Name
input
CAN bus low level signal
input
No terminal resistor is connected between 485+ and 485-.
A 120 Ω terminal resistor is connected between 485+ and 485-.
No terminal resistor is connected between CAN_H and
CAN_L.
A 120 Ω terminal resistor is connected between CAN_H and
CAN_L.
2
OFF CANopen
OFF CAN master/slave
On: The expansion card is connecting with the control board.
Blinks periodically (cycle: 1s; on: 0.5s; off: 0.5s): The expansion card
is connected with the control board.
Off: The expansion card is disconnected from the control board.
On: The communication card is in the operating state.
Blinks periodically (cycle: 0.5s; on: 0.25s; off: 0.25s): The
communication card is in the pre-operation state.
Off: A fault occurs; the reset pin of the communication card and the
power supply are not properly connected; the expansion card is in a
stopped state.
On: The CAN controller bus is off; a fault occurs on the VFD;
received frame lost or incorrect.
Off: The communication card is in the working state.
On: The expansion card is powered on.
Off: The expansion card is not powered on.
Description
SW2
Protocol type
Function
