INVT Goodrive350-19 Series Operation Manual page 170

Goodrive350-19 Series VFD for Crane
Function
Name
code
Hold time of
P01.30 short-circuit braking
for start
Hold time of
P01.31 short-circuit braking
for stop
Pre-exciting time for
P01.32
jogging
Starting frequency
P01.33 of braking for stop
in jogging
P01.34 Sleep delay
Group P02—Parameters of motor 1
Function
Name
code
P02.00 Type of motor 1
Rated power of AM
P02.01
Rated frequency of
P02.02
AM 1
Rated speed of AM
P02.03
Rated voltage of
P02.04
AM 1
Rated current of AM
P02.05
Stator resistance of
P02.06
AM 1
Rotor resistance of
P02.07
AM 1
to enter short-circuit braking.
During stop, if the running frequency of VFD is
lower than the starting frequency of brake for
stop (P01.09), set P01.31 to a non-zero value
to enter short-circuit braking for stop, and then
carry out DC braking in the time specified by
P01.12. (Refer to the descriptions for
P01.09–P01.12.)
P01.29 setting range: 0.0–150.0% (of the rated
VFD output current)
Setting range of P01.30: 0.0–50.0s
Setting range of P01.31: 0.0–50.0s
0–10.000s
0–P00.03
0–3600.0s
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0.1–3000.0kW
1
0.01Hz–P00.03 (Max. output frequency)
1–60000RPM
1
0–1200V
0.8–6000.0A
1
0.001–65.535Ω
0.001–65.535Ω
Description
Description
-158-
Function parameters
Default Modify
○
0.00s
○
0.00s
○
0.000s
○
0.00Hz
○
0.0s
Default Modify
◎
0
Model
◎
depended
◎
50.00Hz
Model
◎
depended
Model
◎
depended
Model
◎
depended
Model
○
depended
Model
○
depended
