Goodrive350-19 Series VFD for Crane
Function
Name
code
LED keypad digital
P08.42
control setting
LED keypad digital
P08.43 potentiometer
integral rate
UP/DOWN terminal
P08.44
control setting
Description
0: No
1: Yes
0x000–0x1223
Ones place: Frequency adjustment selection
0: Both the ∧/∨ key and digital potentiometer
can be used for the control.
1: Only the ∧/∨ key can be used for the
control.
2: Only the digital potentiometer can be used
for the control.
3: Both the ∧/∨ key and digital potentiometer
can be used for the control.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running when
multi-step speed running has the priority
LED hundreds place: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
LED thousands place: Indicates whether to
enable the integral function through the ∧/∨
key and digital potentiometer.
0: Enable the integral function
1: Disable the integral function
0.01–10.00s
0x000–0x221
Ones place: Frequency setting selection
0: The setting made through UP/DOWN is
valid.
1: The setting made through UP/DOWN is
invalid.
Ones place: Frequency control selection
0: Valid only when P00.06 = 0 or P00.07 = 0
-205-
Function parameters
Default Modify
○
0x0003
○
0.10s
○
0x000
