INVT Goodrive350-19 Series Operation Manual page 188

Goodrive350-19 Series VFD for Crane
Function
Name
code
Forward current
P04.46 setting in I/F mode
for AM 2
Proportional
P04.47 coefficient in I/F
mode for AM 2
Integral coefficient
P04.48
in I/F mode for AM 2
Starting frequency
P04.49 for switching off I/F
mode for AM 2
End frequency for
P04.50 switching off I/F
mode for motor 1
End frequency for
P04.51 switching off I/F
mode for motor 2
Reverse current
P04.52 setting in I/F mode
for AM 1
P04.53 Reverse current
Description
Note: The I/F mode is not applicable to
conical motors.
When I/F control is adopted for AM 2, this
parameter is used to set the output current. The
value is a percentage in relative to the rated
current of the motor.
Setting range: 0.0–200.0%
When I/F control is adopted for AM 2, the
function code is used to set the proportional
coefficient of output current in closed-loop
control.
Setting range: 0–5000
When I/F control is adopted for AM 2, the
function code is used to set the integral
coefficient of output current in closed-loop
control.
Setting range: 0–5000
When I/F control is adopted for AM 2, this
parameter is used to set the starting frequency
for switching off the output current closed-loop
control. When the output frequency is lower
than the value of this parameter, the current
closed-loop control in the I/F control mode is
enabled; and when the output frequency is
higher than P04.51, the current closed-loop
control in the I/F control mode is disabled.
Setting range: 0.00–20.00Hz
P04.44–P00.03
P04.49–P00.03
0.0–200.0%
0.0–200.0%
-176-
Function parameters
Default Modify
○
120.0%
○
350
○
150
○
10.00Hz
○
25.00Hz
○
25.00Hz
○
120.0%
○
120.0%
