Goodrive350-19 Series VFD for Crane
Expansion card
The following figure shows the installation diagram and a VFD with expansion cards installed.
EC 1
EC 1
EC 2
EC 2
EC 3
EC 3
EC installation diagram
Diagram of ECs installed
Figure A-1 VFD of 7.5 kW or higher with expansion cards installed
EC 1
EC 1
EC 2
EC 2
ECs installing
ECs installed
Figure A-2 VFD of 5.5kW or lower with expansion cards installed
-420-
