Goodrive350-19 Series VFD for Crane
Dimension drawings
W1
D1
W2
W2
3- ø22.0
W3
D2
H1
H2
6- ø12.0
D2
Figure C-22 Floor mounting for 660V 400–630kW VFD models
Outline
Mount dimensions
Hole
Net
Gross
dimensions
(mm)
VFD model
diameter
Screw
weight
weight
(mm)
(mm)
(kg)
(kg)
W1
H1
D1
W2
W3
H2
D2
400–630kW
620 1700 560
230
572 1678 240
ø 22/12
M20/M10
350
407
-476-
