Goodrive350-19 Series VFD for Crane
Function
Name
code
P27.20
C_MoP9
P27.21
C_MoP10
Digital input
P27.22
terminal status of
programmable card
Digital output
P27.23
terminal status of
programmable card
AI1 of the
P27.24
programmable card
AO1 of the
P27.25
programmable card
Length of data sent
by programmable
P27.26
card and PZD
communication
object
Description
Note: Used to monitor/view the MoP8 value
of the programmable card.
-9999–32767
Note: Used to monitor/view the MoP9 value
of the programmable card.
-9999–32767
Note: Used to monitor/view the MoP10 value
of the programmable card.
0x00–0x3F
bit0: PS1
bit1: PS2
bit2: PS3
bit3: PS4
bit4: PS5
bit5: PS6
0x00–0x03
bit0: PRO1
bit1: PRO2
0–65535
Relative to 0–10.00V/0.00–20.00mA
Note: It is the input AI1 value of the
programmable card.
0–65535
Relative to 0–10.00V/0.00–20.00mA
Note: The function code is used to display
the AO1 value from the programmable card.
0x00–0x28
Ones place: Quantity of data sent from the
programmable card and VFD (that is, quantity
of data sent from the programmable card + from
VFD sending table 1 + from VFD sending table
2)
0: 0+24+60
1: 12+24+60
2: 24+24+60
3: 36+24+60
4: 48+24+60
5: 60+48+60
6: 72+24+36
-288-
Function parameters
Default Modify
0
0
0x00
0x00
0
0
0x03
