INVT Goodrive350-19 Series Operation Manual page 517

Goodrive350-19 Series VFD for Crane
VFD power
315kW
355kW
400kW
450kW
500kW
Note:

The rated input voltage drop of input reactor is designed to 1.5%.

The rated output voltage drop of output reactor is designed to 1%.

For the model selection for paralleled VFDs, see the operation manual for Goodrive series VFDs
in parallel connection.
VFD power
1.5kW
2.2kW
4kW
5.5kW
7.5kW
11kW
15kW
18.5kW
22kW
30kW
37kW
45kW
55kW
75kW
90kW
110kW
132kW
160kW
185kW
200kW
220kW
Input reactor
GDL-ACL0580-4AL
Standard
Standard
Standard
Standard
Table D-7 Filter model selection for 380V VFDs
Input filter
Passive harmonic
filter
GDL-H0006-4AL
GDL-H0006-4AL
GDL-H0014-4AL
GDL-H0020-4AL
GDL-H0025-4AL
GDL-H0032-4AL
GDL-H0040-4AL
GDL-H0047-4AL
GDL-H0056-4AL
GDL-H0070-4AL
GDL-H0080-4AL
GDL-H0100-4AL
GDL-H0130-4AL
GDL-H0160-4AL
GDL-H0190-4AL
GDL-H0225-4AL
GDL-H0265-4AL
GDL-H0320-4AL
GDL-H0400-4AL
GDL-H0400-4AL
GDL-H0485-4AL
DC reactor
GDL-DCL0675-4AL
GDL-DCL0810-4AL
GDL-DCL0810-4AL
GDL-DCL1000-4AL
GDL-DCL1000-4AL
Output filter
dv/dt filter
GDL-DUL0005-4CU
GDL-DUL0005-4CU
GDL-DUL0010-4CU
GDL-DUL0014-4CU
GDL-DUL0020-4CU
GDL-DUL0025-4CU
GDL-DUL0032-4CU
GDL-DUL0040-4AL
GDL-DUL0045-4AL
GDL-DUL0060-4AL
GDL-DUL0075-4AL
GDL-DUL0100-4AL
GDL-DUL0120-4AL
GDL-DUL0150-4AL
GDL-DUL0180-4AL
GDL-DUL0220-4AL
GDL-DUL0260-4AL
GDL-DUL0320-4AL
GDL-DUL0400-4AL
GDL-DUL0400-4AL
GDL-DUL0480-4AL
-505-
Optional peripheral accessories
Output reactor
GDL-OCL0660-4AL
GDL-OCL0660-4AL
GDL-OCL0720-4AL
GDL-OCL0820-4AL
GDL-OCL1000-4AL
Sine-wave filter
GDL-OSF0005-4AL
GDL-OSF0005-4AL
GDL-OSF0010-4AL
GDL-OSF0014-4AL
GDL-OSF0020-4AL
GDL-OSF0025-4AL
GDL-OSF0032-4AL
GDL-OSF0040-4AL
GDL-OSF0045-4AL
GDL-OSF0060-4AL
GDL-OSF0075-4AL
GDL-OSF0095-4AL
GDL-OSF0120-4AL
GDL-OSF0150-4AL
GDL-OSF0180-4AL
GDL-OSF0220-4AL
GDL-OSF0260-4AL
GDL-OSF0320-4AL
GDL-OSF0400-4AL
GDL-OSF0400-4AL
GDL-OSF0480-4AL
