INVT Goodrive350-19 Series Operation Manual page 491

Goodrive350-19 Series VFD for Crane
Name
3m keypad cable
Note:

The LCD keypad is equipped with a real-time clock, which can run properly after being installed
with batteries even if the power line is disconnected. The clock battery (type: CR2032) is user
purchased.

The LCD keypad has the parameter copying function.

If you need install the keypad externally (that is, on another position rather than on the VFD), you
can use M3 screws to fix the keypad, or you can use the keypad installation bracket to install the
keypad. When installing the keypad externally, use an extension cable with a standard RJ45
crystal head for connection.
No. Name
(1)
Status
1
(2)
indicator
(3)
(4)
2 Keys
(5)
Description
Keypad cable; L=3M(CHV-SE)
1
12
5
4
6
3
7
11
9
Figure D-1 Keypad
RUN
TRIP
QUICK/JOG
Function key
2
13
8
14
10
15
Description
Run indicator
On: The VFD is running.
Blinking: The VFD is in parameter autotuning.
Off: The VFD is stopped.
Fault indicator
On: Faulty
Blinking: Pre-alarm
Off: Normal
Short-cut key indicator, which displays
different state under different functions, see
definition of QUICK/JOG key for details.
The function of function key varies with the
menu.
-479-
Optional peripheral accessories
Order No.
37005–00022
