Goodrive350-19 Series VFD for Crane
Function
Name
code
Upward limit
P93.42 position calibrated
pulses
Upward limit
P93.43 position offset
pulses
Upward limit
P93.44 position DEC pulse
threshold
Group P94––Hoisting status display
Function
Name
code
P94.00 Alarm display value
Description
function is invalid within 1 minute; 1 minute
later, the function takes effect, and it is
automatically reset to 3.
0–65535
Unit: x100
During upward running, if the present counting
pulses are detected less than P93.42 or
P93.43, the A-PSP alarm is reported.
0–65535
Unit: x100
0–65535
Unit: x100
During upward running, if the present counting
pulses are detected less than P93.44, the
system decelerates to P91.35 according to the
time specified by P01.26.
Description
0–21
0: None
1: Input phase loss alarm (A- SPI)
2: Upward position limit alarm (A-LU)
3: Downward position limit alarm (A-Ld)
4: Low voltage protection alarm (A-LvP)
5: Overload protection alarm (A-OL)
6: Brake failure alarm (A-bS)
7: Brake feedback alarm (A-FA)
8: Loose rope protection alarm (A-SL)
9: PT100 detected overtemperature alarm
(A-Ot1)
10: PT1000 detected overtemperature alarm
(A-Ot2)
11: PT100 disconnection alarm (A-Pt1)
12: PT1000 disconnection alarm (A-Pt2)
13: PTC detected overtemperature alarm
(A-Ptc)
14: AI detected overtemperature alarm (A-AOt)
-343-
Function parameters
Default Modify
○
1000
○
400
○
3000
Default Modify
●
0
