MERLIN LEGEND Communications System Release 5.0
System Programming 555-650-111
3 Common Administrative Procedures
Memory Card
Figure 3-5.
Backup
Use this procedure to make a copy of your customized system data. You should
create a backup at least three times during system installation (so that
programmed information is not lost) and once after each system upgrade, service
technician visit, or major system reconfiguration.
The Inspect feature (Inspct or
backup files on the memory card prior to initiating the backup procedure. The
attributes included on the Inspect screen are the filename, the time and date of
the file creation/update, the location of the system programming port, and
information about the system software release from which the backup was made.
The list of backup files contains three manual backup filenames and two
automatic backup filenames. The default names of the manual backup files are
*****,
BACK1.
PROCESSOR
MODULE
Push in
to remove
Memory
Card
Inserting the Memory Card
*****, and
BACK2.
Error/Status Code
Display
PCMCIA
Interface Slot
IN S E R
T
C O P
Y R IG
A L L
H T ©
R IG
1 9 9
H T S
3 A T
R E S
& T
E R V
E D
Memory
Card
Alarm Status
LED
3
) is available to view the attributes of the
*****. When you select one of the
BACK3.
Issue 1
June 1997
Page 3-242
