24.6.7 I C status register 2 (I2C_SR2)
Address offset: 0x18
Reset value: 0x0000
Note: Reading I2C_SR2 after reading I2C_SR1 clears the ADDR flag, even if the ADDR flag was
set after reading I2C_SR1. Consequently, I2C_SR2 must be read only when ADDR is found
set in I2C_SR1 or when the STOPF bit is cleared.
15 14 13
r r r
Bits 15:8 PEC[7:0] Packet error checking register
Bit 7 DUALF: Dual flag (Slave mode)
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 6 SMBHOST: SMBus host header (Slave mode)
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 5 SMBDEFAULT: SMBus device default address (Slave mode)
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 4 GENCALL: General call address (Slave mode)
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 3 Reserved, must be kept at reset value
12 11 10 9
PEC[7:0]
r r r r
This register contains the internal PEC when ENPEC=1.
0: Received address matched with OAR1
1: Received address matched with OAR2
0: No SMBus Host address
1: SMBus Host address received when SMBTYPE=1 and ENARP=1.
0: No SMBus Device Default address
1: SMBus Device Default address received when ENARP=1
0: No General Call
1: General Call Address received when ENGC=1
Inter-integrated circuit (I
8 7 6
SMB
DUALF DEFAU
HOST
r r r
