USB on-the-go full-speed (OTG_FS)

43.15.15 OTG power down register (OTG_GPWRDN)

Address offset: 0x058
Reset value: 0x0000 0010
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:24 Reserved, must be kept at reset value.
Bit 23 ADPIF: ADP interrupt flag
Bits 22:1 Reserved, must be kept at reset value.
Bit 0 ADPMEN: ADP module enable
43.15.16 OTG ADP timer, control and status register
(OTG_GADPCTL)
Address offset: 0x060
Reset value: 0x0000 0000
The OTG_GADPCTL register must be accessed as follows:
•
In order to read from the OTG_GADPCTL register, program AR=0b01 and keep polling
till AR=0b00. The core updates the other fields of this register and makes AR=0b00.
Read values of this register are valid only when AR=0b00.
•
In order to write to the OTG_GADPCTL register, program AR=0b10 along with the
values for the other fields and keep polling till AR=0b00. When AR becomes 0b00, it
means that the programmed value has taken effect inside the core.
31 30 29
Res. Res. Res.
15 14 13
r r r
