■ Word Alignment
●
Program access
An FR family program must be placed at an address that is a multiple of 2.
Bit 0 of the PC is set to "0" if the PC is updated when an instruction is executed.
Bit 0 can be set to "1" only if an odd-number address is specified as the branch address.
If Bit 0 is set to "1", however, Bit 0 is invalid and an instruction must be placed at the address that is a
multiple of 2.
No odd-number address exception exists.
●
Data access
When FR family data is accessed, forced alignment is applied as described below to the address based on
the width.
Word access:
Halfword access: An address must be a multiple of 2. (The lowest-order bit is forcibly set to "0".)
Byte access:
During word or halfword data access, some of the bits in the result of calculating an effective address are
forcibly set to "0".
For example, in @(R13, Ri) addressing mode, the register before addition is used without change in the
calculation (even if the lowest-order bit is "1") and the low-order bits are masked. A register before
calculation is not masked.
[Example] LD @(R13, R2), R0
An address must be a multiple of 4. (The lowest-order 2 bits are forcibly set to "00".)
-
R13 00002222
R2 00000003
+)
Addition result 00002225
Address pin 00002224
H
H
H
Lower 2 bits forcibly masked
H
