urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 629

The following table shows the meaning of the fields for the Relay Actuator 1060/84 and the version for
which the field is present.
GENERAL SETTINGS
Name
MAC Address
IP Address
Device Code
Location
MT124-032M
Figure 756: Relay actuator 1060/84 (part 3)
v. 3.04/v. 2.07/v. 4.05
Name to assign to the Relay Actuator. If no name is assigned, the
field is forced with the MAC address.
MAC address associated to the Relay Actuator.
IP address associated to the Relay Actuator. Field visible only if
manual network configuration is set in system parameters. Value
that cannot be changed.
Value that cannot be changed.
Position in the system topology: it is possible to move the device to
another topological node by pressing the "Move" button.
Table 80: General settings
629
