- Page 1 SECTION 4B (REV.B) APARTMENT VIDEO DOOR PHONE STATIONS Download from: www.urmetdomus.com Technical Manuals area sec.4b −−−− BIBUS 2 Ed. VOP - Technical Manual...
-
Page 2: Table Of Contents
SECTION 4B CONTENTS BIBUS II^ Ed. VOP SYSTEM Sec. Pag. APARTMENT VIDEO DOOR PHONE STATIONS ATLANTICO BLACK AND WHITE VIDEO DOOR PHONE SPECIFICATIONS....................................4b ....TECHNICAL SPECIFICATIONS ................................4b ....ATLANTICO COLOUR VIDEO DOOR PHONE Ref. 1702/40 SPECIFICATIONS....................................4b ....TECHNICAL SPECIFICATIONS ................................4b ....ATLANTICO VIDEO DOOR PHONE ATLANTICO BRACKETS FOR BIBUS II^ ED. -
Page 3: Atlantico Black And White Video Door Phone
ATLANTICO BLACK AND WHITE VIDEO DOOR PHONE SPECIFICATIONS - TECHNICAL SPECIFICATIONS - ATLANTICO BRACKETS ATLANTICO BLACK AND WHITE VIDEO DOOR TECHNICAL SPECIFICATIONS PHONE Power voltage: 16 ÷ 18,5Vdc Working uptake: max 0,35A Stand-by: Working power: max 6,5W CCIR version Vertical frequency: 50Hz ±... -
Page 4: Atlantico Colour Video Door Phone Ref. 1702/40
ATLANTICO COLOUR VIDEO DOOR PHONE Ref. 1702/40 SPECIFICATIONS - TECHNICAL SPECIFICATIONS ATLANTICO COLOUR VIDEO DOOR PHONE TECHNICAL SPECIFICATIONS Ref. 1702/40 Power voltage: 16 ÷ 18.5Vdc Working uptake: max. 0.35A Stand-by: Working power: max. 6.5W CCIR version: Vertical frequency: 50Hz ± 2Hz Horizontal frequency: 15625 ±... -
Page 5: Atlantico Video Door Phone
ATLANTICO VIDEO DOOR PHONE ATLANTICO BRACKETS FOR BIBUS II^ ED. VOP SYSTEMS Ref. 1202/954 INSTALLATION ATLANTICO BRACKETS FOR BIBUS II^ ED. Bracket VOP SYSTEMS Ref. 1202/954 Atlantico video door phone are provided without fastening bracket which must be purchased separately. •... -
Page 6: Programming
ATLANTICO VIDEO DOOR PHONE PROGRAMMING - COLOURED MASK KIT PROGRAMMING COLOURED MASK KIT The procedure for programming video door phone user codes is the same The video door phone can be customised by replacing the front mask as for Bibus 2nd edition door phones. Go to the apartment, press the door and add-on name tag with those contained in the Ref. -
Page 7: Artico Video Door Phone Ref. 1705/1
ATLANTICO VIDEO DOOR PHONE Ref. 1705/1 SPECIFICATIONS - TECHNICAL FEATURES ARTICO VIDEO DOOR PHONE Ref. 1705/1 200 mm 83 mm A Door opener button. B1 Auxiliary button: used for special functions. Artico offers the most modern technology applied to picture display and B2 Auxiliary button: used for calling the concierge station and the best quality/price ratio. -
Page 8: Artico Brackets For Bibus Ii^ Ed. Vop Ref. 1705/954
ATLANTICO VIDEO DOOR PHONE Ref. 1705/1 ARTICO BRACKETS FOR BIBUS II^ ED. VOP Ref. 1705/954 - INSTALLATION PROGRAMMING ARTICO BRACKETS FOR BIBUS II^ ED. VOP Ref. 1705/954 Ref. 1705/1 D IP Artico video door phone is provided without fastening bracket which must be purchased separately. -
Page 9: Auto-On
ATLANTICO VIDEO DOOR PHONE Ref. 1705/1 FRONT GLASS REPLACEMENT Operation is described below. Both video door phones (and the FRONT GLASS REPLACEMENT door phone connected in parallel where relevant) ring when a call is received but only the “master” monitor (i.e. the one connected directly The video door phone can be customised by replacing the front glass. -
Page 10: Scaitel Black And White Video Module Ref. 1732/1
SCAITEL BLACK AND WHITE VIDEO MODULE Ref. 1732/1 SPECIFICATIONS SCAITEL COLOUR VIDEO MODULE Ref. 1732/41 SPECIFICATIONS SCAITEL BLACK AND WHITE VIDEO MODULE SCAITEL COLOUR VIDEO MODULE Ref. 1732/1 Ref. 1732/41 The Scaitel video module Ref. 1732/1 has a 4” fl at screen black The Scaitel colour video module Ref. -
Page 11: Scaitel Video Module
SCAITEL VIDEO MODULE VIDEO MODULE BRACKET Ref. 1732/957 - INSTALLATION TABLE MOUNTED KIT FOR SCAITEL MONITOR Ref. 1732/56 VIDEO MODULE BRACKET Ref. 1732/957 TABLE MOUNTED KIT FOR SCAITEL MONITOR Ref. 1732/56 Use the tabletop transformation kit Ref. 1732/56. Proceed as follows: •... - Page 12 −−−− sec.4b BIBUS 2 Ed. VOP - Technical Manual...
