urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 265

The available commands depend on how the output has been configured, i.e. monostable or bistable. In
case of monostable output, only the "ACTIVATE" and "DISACTIVATE'' commands are available. In the other
case, the available commands are "ON", "OFF" and "SWITCH". For more details, see APPENDIX A:
Configuration parameters of IPerCom devices.
The "DISACTIVATE" command in monostable mode is present only on the Relay Actuator 1060/84 v.
4.05 starting from version 2.1.0 of IPerCom.
Press the "OK" button to add the set output as shown below:
Figure 301: List of outputs associated with the activation rule
Different outputs can be associated with the same event by pressing "Add New Output" and repeating the
steps shown above. Since these are single outputs, the "'Scenario'" item will appear in brackets in the
"Group Name" column. It is possible to add groups of previously commands created using the
"Automation" function on the "Command Sets"' tab (see dedicated paragraph Creating a scenario). In this
case, the" Scenario" column shows the name given to the previously created group of commands.
Once configuration of the activation rule is finished, press the "OK" button to end the rule creation
procedure.
MT124-032N 265
