urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 631

IPerTAlk Server / IPerTAlk Server V1
The following table shows the meaning of the fields for the IPerTAlk Server / IPerTAlk Server V1.
General Settings
Name
MAC address
IP Adress
Device code
Location
The IPerTAlk Server V1 item appears only if the network addressing chosen for the IPerCom system
is static and refers to the integration of the IPerCom 3.1.0 system with the IPerTAlk 2.2.10 system or
higher (which mandatorily requires static addressing for the IPerCom system). On the contrary, the
IPerTAlk Server item appears with both dynamic and static network addressing and refers to the
first integration of the IPerCom 2.2.0 system with the IPerTAlk 2.1.4 system or higher (up to and
including version 2.2.3), which allowed below:
- audio or audio-video calls from Ipercom calling stations to iPerTAlk extensions;
- auto-on function from iPerTAlk extensions to Ipercom calling stations;
- audio or audio-video calls from iPerTAlk extensions to Ipercom Switchboard and vice
versa.
MT124-032M
Figure 757: IPerTAlk Server / IPerTAlk Server V1
Name to assign to the IPerTAlk Server / IPerTAlk Server V1.
MAC address associated with the IPerTAlk Server / IPerTAlk
Server V1.
IP address associated with the IPerTAlk Server / IPerTAlk
Server V1. This field is visible only if a manual network
configuration has been set in the system parameters. Not
editable value.
Not editable value.
Position in the system topology: it is possible to move the
device to another topological node pressing the "Move"
button.
Table 84: General settings for IPerTAlk Server / IPerTAlk Server V1
settings
631
