urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 511

3. Sending the position from all other MAX video door phones to the selected MAX video door phone
For all MAX video door phones of the system, except the selected one, it will be necessary to fill in the fields
shown in the previous figure and press "SEND LOCATION" to send these data to the MAX video door phone
that is in acquisition mode.
This operation can be performed contemporaneously by several people to speed it up.
Once the positions from all MAX video door phones have been sent, it is necessary to go back to the
selected MAX video door phone and, after checking that the actual number of MAX video door phones to be
configured is indicated in the "Number of devices acquired" field, press "SEND TO CONFIGURATOR".
IPerCom Configurator will then be opened (after entering the installer password), showing the
automatically updated configuration, with all the MAX video door phones of the system added in the
relevant topological nodes.
Case of manual network settings): Mode 4 for adding devices only works if the "System" tab is as
"Automatic" network setting. Therefore, this mode cannot be used in the case of manual network
configuration (device static IP address).
Sending the default position): if you leave all the fields unchanged in the window in Figure 426 and
press the "SEND POSITION" button, a default position is sent for the MAX monitor: this position, in
case of Kit Villa type projects, is that of the apartment; for all other types of project, the default
position is instead the topological node at the highest system level.
MT124-032N
Figure 643: Updating acquisitions from non-configured MAX video door phones
511
