urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 227

7.1.3 System IPerCom in IPerCloud mode
The creation of the configuration of IPerCom systems in IPerCloud mode must be done exclusively starting
from IPerCom Installer Tools (with authentication on Urmet Cloud and CallMe Manager support enabled)
and not from the video door phones that integrate the configurator (VOG
Any changes must also always be made by IPerCom Installer Tools starting from the relevant project. This is
necessary to always have the installer site aligned with the building manager site transferred via IPerCom
Installer Tools in CallMe.
Given the above, to configure an IPerCom system in IPerCloud mode it is necessary:
•
evaluate whether it is necessary to add a 1060/1 Server to the configuration;
•
configure the relevant apartments in IPerCloud mode.
These aspects are explained in detail in the following paragraphs.
7.1.3.1 Addition in configuration of a Server 1060/1 on an IPerCom system in IPerCloud mode
In IPerCom systems in IPerCloud mode the choice of the calling station model and the number of IPerCloud
apartments may require the presence of a Server 1060/1 for the system to function correctly.
Depending on the two variables reported above, the Server 1060/1 is not required in the following 3 types
of system configurations:
C 1:
ONFIGURATION
•
calling stations of type Modular Calling Station with 1060/48;
•
a maximum of 200 IPerCloud apartments.
To this system configuration it is possible to add one or more calling stations of the type Entry Panel
1060/33-34 and/or Entry Panel 1060/21.
C 2:
ONFIGURATION
•
calling stations of type Entry Panel 1060/33-34;
•
a maximum of 32 IPerCloud apartments.
To this system configuration it is possible to add one or more calling stations of the type Entry Panel
1060/21.
MT124-032N
7
, MAX or Basic).
227
