7.1.5 Activations
The "activation rules" (more briefly "activations") allow defining the behaviour of the relay outputs in
relation to events that can occur within the IPerCom system.
The devices that provide the control relays output are:
- Relay Actuators 1060/84: two fully independent relay outputs and two inputs,
- Lift Interface 1060/37: 24 relay outputs and one input,
- Entry Panel 1060/33-34-71-74-75-78: only the relay output that controls the gate,
- Entry Panel 1060/21: only the relay output that controls the gate,
- Call Module 1060/12-13-17-18-23: only the relay output that controls the gate,
- Modular Calling Station with 1060/48: only the relay output that controls the gate.
The devices Relay Actuator 1060/84 and Lift Interface 1060/37 connect directly to the IP network. For the
other devices it is necessary to set the gate as the output of a relay actuator in the configurator (see
paragraph Gate contact used as output of a Relay
The relay output connected to the gate of a calling station can function alternatively as the output of
a relay actuator or as an output that controls a gate.
To program the outputs of the Relay Actuator, follow the instructions on the device configuration page
(APPENDIX A: Configuration parameters of IPerCom
For the programming mode of Lift Interface outputs in Lift Interface mode, follow the instructions in
paragraph Lift Interface. In Relay Actuator mode, follow the Relay Actuator device configuration page
(paragraph APPENDIX A: Configuration parameters of IPerCom
MT124-032N
Actuator).
devices).
devices).
