7 The configurator
The configurator allows defining the system topology, associating the various devices to the system nodes,
creating directories, activation rules, access control rules, residents, and non-residents, setting the
operating mode of the system.
The configurator is integrated in both IPerCom Installer Tools and the MAX, VOG
phones and the operating mode is similar.
In both cases it is necessary to create the system configuration by defining (as described later) the system
project. In the next paragraphs the use of the configurator within IPerCom Installer Tools is explained.
7.1 Creating or editing the configuration file from IPerCom Installer Tools
The creation (or modification) of the configuration is done through the "Configuration" tab, after opening a
project.
The buttons to create a new configuration or modify an existing one are shown below and are active
according to the description below:
•
"Create", to create a new configuration (if you are not connected to a system or you are connected
to a system without configuration);
•
"From File", to import the configuration from an external .ccf file (with the constraints described in
the previous paragraphs, connected or not connected to a system) and modify it;
•
"From system", to import the configuration from the system to which you are connected (with the
constraints described in the previous paragraphs) and modify it;
•
"Edit", to edit an already existing configuration (connected or not connected to a system).
It is also possible to modify a configuration by opening directly a file with the ccf extension (that is, by
double clicking with the mouse on the file in question). After doing this, you are asked to enter the installer
password, with which the configuration file was saved and you can make changes. If the configuration file
was created through the 3.0.0 configurator of IPerCom Installer Tools and has CallMe Manager support
enabled, it is not possible to modify and save the configuration except through the same configurator
started by IPerCom Installer Tools, as shown by following message:
MT124-032N
Figure 205: configuration not editable
