urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 514

This window shows in sequence:
•
the "Devices with the same configuration", i.e. devices that at that moment have the same
configuration present on the current device;
•
the "Devices not in configuration", i.e. devices that have not been included in the configuration
present on the current device;
•
the "Devices from factory or with an older configuration", i.e. devices which are part of a
configuration older than that on the current device, or which have no configuration at all;
•
the "Devices with a newer configuration", i.e. devices that have a configuration that is more recent
than the one on the current device.
The configuration will be considered complete when all the devices which have been added to the
configuration have received this configuration. In this case, the last two items of the configuration
distribution state ("Devices from factory or with an older configuration" and "Devices with a newer
configuration") will be set to 0, as shown in the following figure.
Automatic device reboot: According to the settings made (e.g. changes to network setting
parameters), some devices may automatically reboot during configuration distribution.
Changes to network settings: If network settings changed, it is recommended to reboot the switch
after having distributed the configuration.
Devices not yet added to the configuration: As mentioned, the configuration distribution will be
deemed complete if all devices have received it correctly. Any non-configured devices which have
not yet been added to the configuration will be indicated under "Devices not in configuration" in the
distribution status window.
514
Figure 647: Indication of completed distribution
MT124-032N
