urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 318

Press the OK button, to see the newly created activation with the associated time profile in the activation
list:
Figure 380: Time profile with activation
The buttons in the "Edit" and "Delete" columns can be used to edit or delete data for each activation,
respectively (via confirmation pop-up).
7.1.5.9.4 Sending alarms to the Switchboard via relay actuator inputs
It is possible to use the ON, OFF, long press and short press events to send one or more alarm signals to the
Switchboards of the system through one or more sensors connected to the Relay Actuator inputs. The
alarm signal is sent when the sensor generates the programmed event.
This can be used using the "Alarms" tab:
Figure 381: "Alarms" tab
318 MT124-032N
