urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 301

Having followed the instructions in the note, the input/output association can be set on the Automation tab
under "Activation Rules", as shown in the following figure:
Press "Add New'' to open the following page:
On this page, you can:
•
give a meaningful name to the new activation in the "Name" field;
•
associate a time profile (previously created) with the activation using the "Time Profile" drop-down
menu (the association is not mandatory) to restrict its validity in time;
•
select the relay actuator inputs and outputs by pressing the respective "Add" buttons.
MT124-032N
Figure 349: "Automation" page, "Activation Rules" tab
Figure 350: Creating a new activation
301
