urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 630

Output 1 and 2
Name
Mode
Input 1 and 2
Name
Mode
Output connected to
input
Normally Open Input
The "Activations" and "Alarms" buttons allow you to create an activation rule and an alarm for a specific
Relay Actuator input.
The Relay Actuator 1060/84 v. 4.05 is the only one to support the "DISABLE" command in
monostable mode (from version 2.1.0 of IPerCom).
A table of the electrical meanings of the on, off, short press and long press events is shown depending on
the input status (normally closed or normally open):
Events
On
Off
Short press
Long press
630
v. 3.04/v. 2.07/v. 4.05
Name to assign to the output. If no name is assigned, the field is
forced by the last 3 pairs of alphanumeric characters of the MAC
address followed by " - Output 1 (2)".
Output relay operating mode: monostable or bistable. If you choose
the monostable mode, you must enter the time during which the
relay operates in this mode. Default value: bistable.
Table 81: Output configuration
Only v. 3.04/v. 4.05
Name to assign to the input
Input operating mode. In bistable mode, the input is set as a switch
(on and off events). In monostable mode, the input is set as a button
(short and long pressure events): in this case the pressure time must
be entered.
If selected, it automatically associates the input with the
corresponding output. If not selected, the input can control several
outputs (also of other Relay Actuators) through the events described
above.
If selected, the input is normally open, otherwise it is normally closed.
Table 82: Input configuration
Normally Open Input
Closed
Open
Closed for T<T0
Closed for T≥T0
Table 83: Meaning of on, off, short press and long press according to input status
Normally Closed Input
Open
Closed
Open for T<T0
Open for T≥T0
